MBTA mTicket

A 6 month cross-platform (iOS and Android) mobile app project for Masabi, a specialist mTicketing company based near London Bridge. The MBTA mTicket application was launched in the Android and iPhone app markets in November 2012, and was a complete success grossing $1 million of sold tickets in the Boston Rail network for the first ten weeks of operation.

MBTA mTicket in the Google Play store.

MBTA mTicket in the Google Play store.

Developing the Front End User Experience

The project focused on building the User Interface for the application, this was done as a HTML5 /JavaScript UI due to the inherent advantages in being able to share code across different platforms. During development, we regularly tested against Android, iOS, BlackBerry, Symbian WebOS and Windows Mobile.

MBTA mTicket Payment Walkthrough

The process for purchasing tickets is straight forward, no complicated steps or black magic.

To purchase a round trip ticket to/from Boston the steps are:

1) Click ‘Buy Tickets’
2) Choose a ‘From’ and ‘To’ Station from the list.
3) Choose a ‘Round Trip’ ticket
4) Choose an existing card (the app stores a payment key after the first time).
5) Enter the Card CVV

mbta.workflow.new1

6) Review your purchase
7) Press ‘Pay Now’
8) DONE!

mbta.workflow.new2

Once the transaction goes through, the ticket is loaded into the My Tickets section. You now have two round trips to Boston waiting for you.

These last few panels are a shot of your ticket. The rectangle at the top shows the current time, the time block moves back and forth, and the three blocks are multi-colored. The color scheme changes on a daily basis according to a scheme that the conductor knows. Once the ticket is used it changes into a grey scheme. The conductor when he approaches will generally glance at the screen, nod with a “thanks” and put a paper slip in the holder above your head. Done.

mbta.workflow.new3

MBTA mTicket in the News

These are some of the online articles that were published before and after launch:

Apr 23rd, 2012

MBTA and Masabi team up for first smartphone rail ticketing system in the US, launching in Boston this fall

Jul 12th, 2012

New York MTA announces smartphone-based ticketing trials aboard Metro-North Railroad


July 11, 2012

New Smartphone App Could Replace Railroad Tickets


Nov 12, 2012

MBTA & Masabi Launch US` First Smartphone Commuter Rail Ticketing System

Jul 11, 2012

Digital train tickets to replace paper for some NY commuters


November 27, 2012

mTicket: MBTA releases mobile ticketing app at South Station

December 04, 2012

mTicket: T reports $225,000 in mobile app ticket sales since November launch

January 15, 2013

mTicket sees $1 million in commuter line sales


November 21st, 2012

What Bostonians Are Thankful For

November 27th, 2012

Mobile Ticketing Coming to MBTA Boats & More Commuter Trains, Riders Can Purchase Monthly Passes


Customer Respose

The MBTA mTicketing app went on to become a huge success shortly after launch. Customers reported a ‘seamless experience’ with ‘great usability’, ‘very convenient’, ‘neat & efficient’ etc.

These are some of the responses the MBTA customers tweeted shortly after launch:

25 Techniques for Javascript Performance Optimization

These are some the techniques I use for enhancing the performance of JavaScript, they have mostly been collected over various years of using the language to improve the responsiveness of websites and web applications.

My thanks go out to Marco of zingzing.co.uk for reminding me of the importance of optimizing JavaScript, and for teaching me some of the techniques below.

Most of the techniques involve common sense once you have understood the underlying problem. I’ve categorised performance-enhancement techniques into 5 broad categories, each with an underlying problem and solution as follows:

1. Avoid interaction with host objects

Repeated interaction with host objects will kill your performance.

THE PROBLEM:

Native JavaScript is compiled into machine code by most scripting engines offering incredible performance boost, however interaction with host (browser) objects outside the javascript native environment raises unpredictability and considerable performance lag, particularly when dealing with screen-rendered DOM objects or objects which cause Disk I/O (such as WebSQL).

THE SOLUTION:

You can’t really get away from DOM, but keep your interaction with in-browser objects to an absolute minimum.

THE TECHNIQUES:

  1. Use fast DOM traversal with document.getElementById().Given the availability of jQuery, it is now easier than ever to produce highly specific selectors based on a combination of tag names, classes and CSS3. You need to be aware that this approach involves several iterations while jQuery loops thorough each subset of DOM elements and tries to find a match. You can improve DOM traversal speeds by picking nodes by ID.
    // jQuery will need to iterate many times until it finds the right element
    var button = jQuery('body div.dialog > div.close-button:nth-child(2)')[0];

    // A far more optimized way is to skip jQuery altogether.
    var button = document.getElementById('dialog-close-button');

    // But if you need to use jQuery you can do it this way.
    var button = jQuery('#dialog-close-button')[0];
  2. Store pointer references to in-browser objects.Use this technique to reduce DOM traversal trips by storing references to browser objects during instantiation for later usage. For example, if you are not expecting your DOM to change you should store a reference to DOM or jQuery objects you are going to use when your page is created; if you are building a DOM structure such as a dialog window, make sure you store a few handy reference to DOM objects inside it during instantiation, so you dont need to find the same DOM object over an over again when a user clicks on something or drags the dialog window.

    If you haven’t stored a reference to a DOM object, and you need to iterate inside a function, you can create a local variable containing a reference to that DOM object, this will considerably speed up the iteration as the local variable is stored in the most accessible part of the stack.

  3. Keep your HTML super-lean (get rid of all those useless DIV and SPAN tags)This is extremely important, the time needed to query and modify DOM is directly proportional the the amount and complexity of HTML that needs to be rendered. Using half the amount of HTML will roughly double the DOM speed, and since DOM creates the greatest performance drag on any complex JavaScript app, this can produce a considerable improvement. See ‘Reduce Number of DOM Elements’ guidance in Yahoo YSlow.
  4. Batch your DOM changes, especially when updating styles.When making calls to modify DOM make sure you batch them up so as to avoid repeated screen rendering, for example when applying styling changes. The ideal approach here is to make many styling changes in one go by adding or removing a class, rather than apply each individual style separately. This is because every DOM change prompts the browser to re-render the whole UI using the boxing model. If you need to move an item across the page using X+Y coordinates, make sure that these two are applied at the same time rather than separately. See these examples in jQuery:
    // This will incurr 5 screen refreshes
    jQuery('#dialog-window').width(600).height(400).css('position': 'absolute')
                           .css('top', '200px').css('left', '200px');
    // Let jQuery handle the batching
    jQuery('#dialog-window').css({
         width: '600px',
         height: '400px',
         position: 'absolute',
         top: '200px',
         left: '200px'
    );
    // Or even better use a CSS class.
    jQuery('#dialog-window').addClass('mask-aligned-window');
  5. Build DOM separately before adding it to the page.As per the last item, every DOM update requires the whole screen to be refreshed, you can minimize the impact here by building DOM for your widget ‘off-line’ and then appending your DOM structure in one go.
  6. Use buffered DOM inside scrollable DIVs.This is an extension of the fourth point above (Keep HTML super-lean), you can use this technique to remove items from DOM that are not being visually rendered on screen, such as the area outside the viewport of a scrollable DIV, and append the nodes again when they are needed. This will reduce memory usage and DOM traversal speeds. Using this technique the guys at ExtJS have managed to produce an infinitely scrollable grid that doesn’t grind the browser down to a halt.

2. Manage and Actively reduce your Dependencies

Poorly managed JavaScript dependencies degrade user experience.

THE PROBLEM:

On-screen visual rendering and user experience is usually delayed while waiting for script dependencies load onto the browser. This is particularly bad for mobile users who have limited bandwidth capacity.

THE SOLUTION:

Actively manage and reduce dependency payload in your code.

THE TECHNIQUES:

  1. Write code that reduces library dependencies to an absolute minimum.Use this approach to reduce the number of libraries your code requires to a minimum, ideally to none, thus creating an incredible boost to the loading times required for your page. You can reduce dependency on external libraries by making use of as much in-browser technology as you can, for example you can use document.getElementById('nodeId') instead of jQuery('#nodeId'), or document.getElementsByTagName('INPUT') instead of jQuery('INPUT') which will allow you to get rid of jQuery library dependency.

    If you need complex CSS selectors use Sizzle.js instead of jQuery, which is far more lightweight (4kb instead of 80kb+).Also, before adding any new library to the codebase, evaluate whether or you really need it. Perhaps you are just after 1 single feature in the whole library? If that’s the case then take the code apart and add the feature separately (but don’t forget to check the license and acknowledge author if necessary).

  2. Minimize and combine your code into modules.You can bundle distinct components of your application into combined *.js files and pass them through a javascript minimizer tool such as Google Closures or JsMin that gets rid of comments and whitespacing. The logic here is that a single minimized request for a 10Kb .js file completes faster than 10 requests for files that are 1-2kb each due to lower bandwidth usage and network latency.
  3. Use a post-load dependency manager for your libraries and modules.Much of your functionality will not need to be implemented until after the page loads. By using a dependency manager (such as RequireJS or head.js) to load your scripts after the page has completed rendering you are giving the user a few extra seconds to familiarise themselves with the layout and options before them. Make sure that your dependency manager can ‘remember’ which dependencies have been loaded so you dont end up loading the same libraries twice for each module. See guidance for Pre-Loading and Post-loading in Yahoo YSLow, and be mindful about loading only what is necessary at each stage of the user journey.
  4. Maximise use of caching (eTags, .js files, etc).Cache is your best friend when it comes to loading pages faster. Try to maximise the use of cache by applying ETags liberally and putting all your javascript into files ending in *.js found in static URI locations (avoid dynamic Java/C# bundle generations ending with *.jsp and *.ashx) . This will tell the browser to use the locally cached copy of your scripts for any pages loaded after the initial one.
  5. Move scripts to the end of the page (not recommended).This is the lazy way of handling post-load dependencies, ideally you should implement a post-load dependency manager, but if you only have one or two scripts to load into the page you can add them at the very end of the HTML document where the browser will start loading them after the page is rendered, giving the user a few extra seconds of interaction.

3. Be disciplined with event binding

Be a ninja when using event handling.

THE PROBLEM:

Browser and custom event handlers are an incredible tool for improving user experience and reducing the depth of the call stack, but since they are hard to track due to their ‘hidden’ execution they can fire many times repeatedly and quickly get out of hand, causing performance degradation.

THE SOLUTION:

Be mindful and disciplined when creating event handlers.

THE TECHNIQUES:

  1. Use event binding but do it carefully.Event binding is great for creating responsive applications, and it can even improve the performance of your code by reducing the depth of the call stack (so you avoid having a function calling a function which calls another function etc). However, because the flow of event execution cannot be traced easily, it is very important that you use event handlers sparingly, you walk through the execution and various user journeys to make sure they are not firing double, and you comment your code well so they next guy (which may be you a few months down the line) can follow what’s going on.
  2. Pay special attention event handlers that fire in quick succession (ie, ‘mouseover’).Browser events such as ‘mouseover’ and ‘resize’ are executed in quick succession up to several hundred times each second, this means that you need to ensure that an event handler bound to either of these events is coded optimally and can complete in less than 2-3 milliseconds. Any overhead greater than that will create a patchy user experience, specially in browsers such as IE that have poor rendering capabilities.
  3. Remember to unbind events when they are no longer needed.Unbinding events is as important as binding them. When you add a new event handler to your code make sure that you provide for it to stop firing when it is no longer needed, ideally by coding in the unbind behaviour at that point. Be careful when using jQuery to bind and unbind events, and make sure your selector points to a unique node, as a loose selector can create or remove more handlers than you intend to.
  4. Learn about event bubbling. Use jQuery.bind() instead of jQuery.live() and jQuery.delegate()If you are going to use event handlers, it is important that you understand how event bubbling propagates an event up the DOM tree to every ancestor node. You can use this knowledge to limit your dependency on event bubbling with approaches such as jQuery.live() and jQuery.delegate() that require full DOM traversal upon handling each event, or to  stop event bubbling for improved performance. See this great post on the subject.
  5. Use ‘mouseup’ instead of ‘click’.Remember that user interaction via the mouse or keyboard fires several events in a specific order. It is useful to remember the order in which these events fire so you can squeeze in your functionality before anything else gets handled, including native browser event handlers.

    A good example of this is to bind your functionality to the ‘mouseup’ event which fires before the ‘click’ event, this can produce a surprising performance boost in older browsers such as IE, making the difference between handling every interaction or missing some of the action if the user triggers clicks many times in succession.

4. Maximise the efficiency of your iterations

String concatenation performance becomes critical during long iterations.

THE PROBLEM:

Due to the processing time used, iterations are usually the first places where you can address performance flaws in an application.

THE SOLUTION:

Get rid of unnecessary loops and calls made inside loops.

THE TECHNIQUES:

  1. Use Array.prototype.join()for string concatenation inside IE.Joining strings using the plus sign (ie var ab = 'a' + 'b';) creates performance issues in IE when used within an iteration. This is because, like Java and C#, JavaScript uses unmutable strings. Basically, when you concatenate two strings, a third string is constructed for gathering the results with its own object instantiation logic and memory allocation. While other browsers have various compilation tricks around this, IE is particularly bad at it.

    A far better approach is to use an array for carrying out the donkey work, creating an array outside the loop, using push() to add items into to the array and then a join() to output the results. See this link for a more in-depth article on the subject.

  2. Harness the indexing power of JavaScript objects.Native JavaScript objects {} can be used as powerful HashMap data structureswith quick-lookup indexes to store references to other objects, acting similarly to the way database indexes work for speeding up search operations by preventing needless looping. You can use this notation to remove the need for iterating through a set of results, by simply calling the index as follows:
    var data = {
      index: {
                "joeb": {name: "joe", surname: "bloggs", age: 29 },
                "marys": {name: "mary", surname: "smith", age: 25 }
                // another 1000 records
             },
      get: function(username) {
                return this.index[username];
             }
    }
  3. Harness the power of array structures with push() and pop() and shift().Array push() pop() and shift() instructions have minimal processing overhead (20x that of object manipulation) due to being language constructs closely related to their low-level assembly language counterparts. In addition, using queue and stack data structures can help simplify your code logic and get rid of unnecessarily loops. See more on the topic in this article.
  4. Take advantage of reference types.JavaScript, much like other C-based languages, has both primitive and reference value types. Primitive types such as strings, booleans and integers are copied whenever they are passed into a new function, however reference types such as arrays, objects and dates are passed only as a light-weight reference.

    You can use this to get the most performance out of recursive functions, such as by passing a DOM node reference recursively to minimise DOM traversal, or by passing a reference parameter into a function that executes within an iteration. Also, remember that comparing object references is far more efficient than comparing strings.

5. Become friends with the JavaScript lexicon

Become a friend of the ECMA Standard and it make your code faster.

THE PROBLEM:

Due to its loosely-typed and free-for-all nature, JavaScript can be written using a very limited subset of lexical constructs with no disciple or controls applied to its use. Using simple function patterns repetitively often leads to poorly thought-out JavaScript that is inefficient in terms of performance and memory usage.

THE SOLUTION:

Learn when and how to apply the constructs of the ECMAScript language standard to maximise performance.

THE TECHNIQUES:

  1. Shorten the scope chainIn JavaScript, whenever a function is executed, a set of first order variables are instantiated as part of that function. These include the immediate scope of a function (the this variable) with its own scope chain, the arguments of the function and all  locally-declared variables. If you try and access a globally-declared variable further up the scope chain, it will take extra effort to traverse up the chain every level util the compiler can wire up the variable you are after. You can thus improve execution by only using the local scope (this), function arguments and locally declared variables inside each function. This article explains the matter further.
  2. Avoid creating functions unnecessarily.For the reasons outlined in the last point, every time a function is created a whole set of objects and variables need to be created and wired up to support function scope and execution. Thus, to improve performance only create functions where it makes sense to encapsulate code in this way.
  3. Make use of ‘this’, by passing correct scope using ‘call’ and ‘apply’.This is particularly useful for writing asynchronous code using callbacks, however it also improves performance because you are not relying on global or closure variables held further up the scope chain. You can get the most out of the scope variable (this) by rewiring it using the special call() and apply() methods that are built into each function. See the example below:
    var Person = Object.create({
      init: function(name) {
         this.name = name;
      },
      do: function(callback) {
         callback.apply(this);
      }
    });
    var john = new Person('john');
    john.do(function() {
        alert(this.name); // 'john' gets alerted because we rewired 'this'.
    });
  4. Learn and use native functions and constructs.ECMAScript provides a whole host of native constructs that save you having to write your own algorithms or rely on host objects. Some examples include Math.floor(), Math.round(), (new Date()).getTime() for timestamps, String.prototype.match() and String.prototype.replace() for regexes, parseInt(n, radix) for changing numeral systems, === instead of == for faster type-based comparsion, instanceof for checking type up the hierarchy, & and | for bitwise comparisons. And the list goes on and on. Make sure you use all these instead of trying to work out your own algorithms as you will not only be reinventing the wheel but affecting performance.
  5. Use ‘switch’ instead of lengthy ‘if-then-else’ statements.This is because  ‘switch’ statements can be optimized more easily during compilation. There is an interesting article in O’Reily about using this approach with JavaScript.



Object-Oriented JavaScript Inheritance

This is simple but crucial stuff in JavaScript. Its easy to forget how to do object-oriented inheritance from scratch when you are dealing with several JS frameworks and each of them has pre-built methods that support this functionality in a slightly different way.

JavaScript is a functional language that uses prototypal inheritance. That means you can use classical inheritance such as that supported by Java and C#, however you need to be disciplined about the way you write code and need do a couple of things every time you add a class to your type hierarchy.

When creating a new class, we are essentially creating a function and assigning a new instance of another function as the prototype. This is the basis of ‘prototypal’ inheritance, ie. if you are dealing with ‘Dog’ type that inherits from an ‘Animal’ class, the template for your dog is a newly created instance of animal.

For Example:

// Create a new class called 'Animal'
var Animal = function() {};

// Create an instance of the 'Animal'
var anAnimal = new Animal();

// Create a class called 'Dog'
var Dog = function() {};

// Assign the template
Dog.prototype = anAnimal;

// Instantiate the dog
var lassie = new Dog();

Abstracting inheritance

I’ve created a simple static method called ‘extend’ on the Object class. Most frameworks do this in one shape or another (ie ExtJS uses Ext.extend(), John Resig likes to use Class.extend() method, Mootools uses new Class(properties) approach etc).

A ‘static’ method means that only the ‘Object’ class template will have it, so we do not pass it over to our children through inheritance. See the following code:

// Create a static 'extends' method on the Object class
// This allows us to extend existing classes
// for classical object-oriented inheritance
Object.extend = function(superClass, definition) {
    var subClass = function() {};
    subClass.prototype = new superClass();
    for (var prop in definition) {
        subClass.prototype[prop] = definition[prop];
    }
    return subClass;
};

This allows us to simplify the process of using object-oriented inheritance by abstracting the prototype assignment into this separate function call.

// Create an 'Animal' class by extending
// the 'Object' class with our magic method
var Animal = Object.extend(Object, {
    move : function() {alert('moving...');}
});

// Create a 'Dog' class that extends 'Animal'
var Dog = Object.extend(Animal, {
    bark : function() {alert('woof');}
});

// Instantiate Lassie
var lassie = new Dog();

// She can move AND bark!
lassie.move();
lassie.bark();

Adding Constructors

But, we seem to have forgotten one thing. What about constructors?

JavaScript uses the function itself as the constructor for a new object. Thus, when we created the Animal object above we could have simply added some sample code to its constructor as follows:

// Assign the name of the animal when it gets instantiated
var Animal = new function(name) {
  this.name = name;
}

var lassie = new Animal('Lassie');
alert('My pets name is: ' + lassie.name);

Thus we can augment our class creation methodology using the same idea:

// Create a 'Subclass' with a constructor
var SubClass = Object.extend(SuperClass, {
    constructor: function(parameter) {
        this.x = parameter;
    },
    method1: function() {
        // ...
    }
});

// Instantiate it
var subClass = new SubClass('value');
alert(subClass.x);

In order to allow this kind of notation, we can modify our ‘extend’ method to take care of this special ‘constructor’ function. This is done as follows:

// Create a static 'extends' method on the Object class
// This allows us to extend existing classes
// for classical object-oriented inheritance
Object.extend = function(superClass, definition) {
    var subClass = function() {};
    // Our constructor becomes the 'subclass'
    if (definition.constructor !== Object)
        subClass = definition.constructor;
    subClass.prototype = new superClass();
    for (var prop in definition) {
    	if (prop != 'constructor')
            subClass.prototype[prop] = definition[prop];
    }
    return subClass;
};

And put it to use by writing minimal code that is meaningful to read and leaves the object-creation abstraction sitting behind the scenes:

// Create the 'Animal' class by extending
// the 'Object' class with our magic method
// this time using a constructor
var Animal = Object.extend(Object, {
    constructor: function(name) {
        this.name = name;
    },
    move: function() {
        alert('moving...');
    }
});

// Instantiate Lassie (as an animal)
var lassie = new Animal('Lassie');

// Now lassie has a name which is
// defined inside the object constructor
alert('My pets name is: ' + lassie.name);

Calling constructors through the inheritance chain.

Now we have come up against a small problem, our ‘Animal’ class can have a constructor, but its child class ‘Dog’ has no way to call this constructor so it can take advantage of the logic for instantiating all animals.

In order to do this we are going to add a special ‘superClass’ property to all of our classes automatically, then use the magic ‘call’ function to call this using the context of the dog instance (to put it in plain english, this will make each ‘Dog’ run the logic for an ‘Animal’).

Lets see, all together now:

// Create a static 'extends' method on the Object class
// This allows us to extend existing classes
// for classical object-oriented inheritance
Object.extend = function(superClass, definition) {
    var subClass = function() {};
    // Our constructor becomes the 'subclass'
    if (definition.constructor !== Object)
        subClass = definition.constructor;
    subClass.prototype = new superClass();
    for (var prop in definition) {
    	if (prop != 'constructor')
            subClass.prototype[prop] = definition[prop];
    }
    // Keep track of the parent class
    // so we can call its constructor too
    subClass.superClass = superClass;
    return subClass;
};

// Create the 'Animal' class by extending
// the 'Object' class with our magic method
// this time using a constructor
var Animal = Object.extend(Object, {
    constructor: function(name) {
        this.name = name;
    },
    move: function() {
        alert('moving...');
    }
});

// Create a 'Dog' class that inherits from it
var Dog = Object.extend(Animal, {
    constructor: function(name) {
        // Remember to call the super class constructor
        Dog.superClass.call(this, name);
    },
    bark: function() {
        alert('woof');
    }
});

// Instantiate Lassie
var lassie = new Dog('Lassie');

// She can move AND bark AND has a name!
lassie.move();
lassie.bark();
alert('My pets name is: ' + lassie.name);

Multiple inheritance using Interfaces

Now its possible to add support for multiple inheritance to our object creation syntax in Javascript. In single-inheritance object-oriented languages such as Java and C#, multiple inheritance (inheriting properties and methods from more than one class chain) is done using Interfaces.

The implementation is a bit more crude than in Java or C#, the reason why is because Javascript, unlike these languages, is not compiled so we cant throw compilation-time errors. This means that when we implement an interface we are limited to checking that the appropriate members are there at runtime and if not we through an error.

So, lets start first with our intended usage for Interfaces:

var SubClass = Object.extend(SuperClass, {
     method1: function() {
         alert('something');
     }
}).implement(Inteface1, Interface2 ...);

Going by this approach, we need to create a method ‘implement’ for every class, since in Javascript our classes are instances of the ‘Function’ object, this means adding this method to Function.prototype.

The code does start to be a bit hairy from this point, its important to point out that the context of this function call (ie this) is the class that we are testing for implementation of a particular interface.

Function.prototype.implement = function() {
    // Loop through each interface passed in and then check
    // that its members are implemented in the context object (this)
    for(var i = 0; i < arguments.length; i++) {
         var interf = arguments[i];
         // Is the interface a class type?
         if (interf.constructor === Object) {
             for (prop in interf) {
                 // Check methods and fields vs context object (this)
                 if (interf[prop].constructor === Function) {
                     if (!this.prototype[prop] ||
                          this.prototype[prop].constructor !== Function) {
                          throw new Error('Method [' + prop
                               + '] missing from class definition.');
                     }
                 } else {
                     if (this.prototype[prop] === undefined) {
                          throw new Error('Field [' + prop
                               + '] missing from class definition.');
                     }
                 }
             }
         }
    }
    // Remember to return the class being tested
    return this;
}

And there you have it! Its important to point out that this is one of many ways to abstract object-orientation in Javascript. There are different approaches, and as a programmer it helps to pick one you are more comfortable with. Personally, I like this approach because of its simplicity, readability, and ease of use:

// Create a 'Mammal' interface
var Mammal = {
    nurse: function() {}
};

// Create the 'Pet' interface
var Pet = {
    do: function(trick) {}
};

// Create a 'Dog' class that inherits from 'Animal'
// and implements the 'Mammal' and 'Pet' interfaces
var Dog = Object.extend(Animal, {
     constructor: function(name) {
          Dog.superClass.call(this, name);
     },
     bark: function() {
          alert('woof');
     },
     nurse: function(baby) {
          baby.food = 100;
     },
     do: function(trick) {
          alert(trick + 'ing...');
     }
}).implement(Mammal, Pet);

// Instantiate it
var lassie = new Dog('Lassie');
lassie.move();
lassie.bark();
lassie.nurse(new Dog('Baby'));
lassie.do('fetch');
alert('My pets name is: ' + lassie.name);

Pepsi Project Refresh

A global-reach social media campaign for renown household brand. This project involved designing an interface for a competition mechanics application with some of the latest technologies such as RESTful AJAX, jQuery, jQT, Qunit, HTML5, GitHub, Ruby on Rails all delivered over Amazon’s E2 Cloud delivery network.

The Pepsi Project Refresh

Pepsi Project Refresh – Global Competition Campaign

The Pepsi Refresh Project is an international social-media campaign aimed principally at teenagers and young adults, Pepsi’s main consumer base.

The project involved working with other skilled interface developers to customize the GUI and enhance an existing competition-mechanics platform (supplied by Global Dawn, a London-based specialist software developer) to provide Pepsi with the ability to create and judge competition rounds using bespoke rules, giving users have the ability to upload content and rate other user’s content all using Pepsi’s familiar blue branding.

Rich User Interface Technology

The principal technology stack of the project was RESTful AJAX over Ruby on Rails, this meant a highly-responsive UI that required minimal refreshing of the browser’s window. The main frameworks used for this were jQuery and QUnit(for unit testing).

Compatibility requirements meant unit-testing across various browser platforms.

A distributed team across several geographical areas meant using a robust and well-known Source Control and Bug-tracking platforms, GitHub, the platform of choice for many open-source projects was used for this purpose. Jira, another excellent solution provided by Atlassian, was used mostly for bug-tracking and task management.

Amazon Cloud

Various Technologies used for the Project

In order to improve high-volume delivery across all international location, the project used Amazons EC2 CloudDelivery Network.

Global Release

At then end of the project, the platform was localised and released across various international site. Russia and Italy being the first two participants in the competition.

Russian Site: platform was localised and delivered across various International Sites.

User-Generated Content

The key to the low-maintenance requirements of the competition is that users generate their own content. They upload videos and images, and they get to vote on videos and images provided by other users. According to Global Dawn’s 1-9-90 competition technology, some users tend to provide the majority of traffic and content in a site, hence these users are rewarded with ‘points’ to spend across the site as they see fit.

Italian Site: Users upload their own content and vote on other people’s content.

Competition mechanics are designed by brand managers (Pepsi in this case), they choose different parameters such as the duration of the competition, number of stages etc.

Markit Environmental Registry

The Markit Environmental Registry is a central repository for tracing the ownership of carbon credits anywhere in the world and is the 1st ranked registry in 2012 Environmental Finance’s survey.

Rich Application for Carbon Market Transactions

Development of a fully Object-Oriented Javascript interface using the latest version of the EXT JS framework, a fully featured AJAX and GUI widget library based on Yahoo UI.

This was a 6 month project going live in September 2010 as part of the Markit suite of environmental products. The Markit Environmental Registry is a central repository for tracing the ownership of carbon credits anywhere in the world and has helped Markit gain 1st place for ‘Best Registry Provider’ in 2012 Environmental Finance’s survey.

While the work was primarily focused on individual paid-for access, there is also a complimentary public view interface that allows non-users to query database directly (written in plain HTML for SEO optimization).

Registry Landing Page

Delivering Features with Optimal Usability

Deliverables include a fully-operating Graphic User Interface compatible with IE (6,7 and 8), Firefox (3.0 upwards), Chrome and Safari in the form of an 8,000 line JavaScript library with 43 compiled javascript classes using object-oriented inheritance for minimal code-repetition and Java nomenclature and namespace breakdown wherever possible (with a view to find a replacement Java programmer) .

AJAX Architecture

The end result is a rich interface for a data-driven web application, with look-and-feel similar to that of a desktop application like Excel or Outlook. The users of the registry can access the following features:

Advanced Dockable Components

Standardised components such as grids (for record lists) allow for easily building functionality with components that can be docked in tab panels or within a popup window. Base components provide key functionality, such as layout, ordering, paging and searching and can be extended depending on the requirements for each section of the application.

Advanced Dockable Components

Simplified Search Criteria

Search criteria is simplified and prioritised to hide items that are less relevant to the user. Searching requires minimal input from the user (usually mouse-scroll and click).

Simplified Search Criteria

Predictive Search

An AJAX favourite. The implementation within the Registry is done using DOM buffering (only the items displayed are being rendered in the browser) which allows for thousands of records to be quickly filtered down to those that fit relevant criteria in milliseconds.

Predictive Search

Context Menus (right mouse button)

Context menus are used for right-clicking on a piece of information to find out relevant actions that can be performed. This is ported from functionality found in desktop application such as Outlook or Excel.

Context Menus

Windowed Interface

Window “lightboxes” are used to display information about individual records. These are pop-ups rendered within the page as modal windows, which provide a high degree of responsiveness in the application and the look-and-feel of traditional desktop applications.

Windowed Interface

Server-Side Validation Messages

Intuitive and appealing server side validation messages (without needing to refresh the page). The fields a user has entered incorrectly are clearly highlighted and provide additional information when hovering above them.

Server Validation

Hierarchical Data Representation (expanding trees)

Data is presented hierarchically wherever relevant, for example a syndication “Basket” used for risk management, can be constructed to contain other items within in. The User Interface displays this as an expandable item, with other items within it.

Hierarchical Data Representation

Object-Oriented Inheritance

The interface is designed as a self-contained JavaScript class library with components (Classes) that inherit from each other. This is done to reduce code-duplication and make the software more manageable.

Object Inheritance

Environmental Registry in the News

Environmental Finance

Markit Environmental Registry named ‘Best Registry Provider
April 2012



Feedback on the Registry

Some of the feedback received on this project:

UserEli Goncalves (End User)
www.personalco2zero.com

13 Sep 2010 – Your new platform really became more practical. Congrats!

UserHelen Robinson (Founder)
www.markitenvironmental.com

20 Sep 2010 – You guys have done a wonderful job, thank you very much!
